| CPU |
Intel® Core™ Ultra 7 Processor 165U (OEM only)
Intel® Core™ Ultra 7 Processor 155U
Intel® Core™ Ultra 5 Processor 135U (OEM only)
Intel® Core™ Ultra 5 Processor 125U
Meteor Lake-U Platform, 15W Processor Base Power (PBP) |
| System Memory |
2 x 262-pin SO-DIMM sockets support up to 64GB DDR5 5600MT/s |
| BIOS |
AMI uEFI BIOS 256 Mbit SPI Flash ROM |
| Audio Codec |
Realtek HD Audio |
| Ethernet |
2 x Intel® Ethernet Controller I226-IT , 10/100/1000/2500 Base-Tx GbE Compatible |
| Expansion |
1 x M.2 B-Key (2242/3042/3052), supports SATA3 / PCIe Gen4x1 / USB 3.2 + SIM slot
1 x M.2 E-Key (2230) for Wi-Fi & BT Module (USB2.0 / PCIe Gen4x1)
1 x IET interface (1 x DDI, 4 x PCIe Gen4x1, 3 x USB2.0, 1 x SMBus, eSPI) |
| Storage through |
1 x M.2 M-Key 2280 (1 x PCIe Gen4x4), supports NVMe
1 x M.2 B-Key 2242, supports SATA (share with expansion slot) |
| Watchdog Timer |
H/W Reset, 1sec. ~ 65535sec. |
| H/W Status Monitor |
CPU & system temperature monitoring and voltages monitoring |
| TPM |
TPM 2.0 |
| Supported OS |
Win 10, Win 11, Linux |
| Mechanical and Environment |
| Operating Temperature |
-40°C ~ 65°C (w/SSD) ambient air flow (w/ 32G DDR5)
-40°C ~ 60°C (w/SSD) ambient air flow (w/ 64G DDR5, Maximum capacity) |
| Storage Temperature |
-30°C ~ 70°C (-22°F ~ 158°F) |
| Operating Humidity |
95% Relative Humidity @ 40°C, non-condensing |
| IP Rating |
IP 50 |
| Regulatory/Compliance |
CE Class B, FCC Class B, UKCA, IP50 |
| Mounting Kit |
Standard: Wall Mount Kit
Optional: Din Rail Mount Kit |
| Dimensions |
Standard: 9.45" x 5.91" x 1.93" (240 x 150 x 49mm)
Optional: 9.45" x 5.91" x 2.95" (240 x 150 x 75mm) (with IET Module) |
| Weight |
4.63 lbs (2.1 kg) |
