This is an OEM Only product.

This product is marked as "OEM Only". OEM products are designed for OEMs with ongoing and consistent order requirements and subject to minimum order quantities. Evaluation units are available without such restrictions. BCM has multiple stocking distributors that may be able to work with OEMs to streamline product deliveries. Please contact BCMSales@bcmcom.com Sales for more information.

ESM-RPL Coming Soon

COMe Module with 13th Gen Intel® Raptor Lake H/P/U-Series BGA Processor

13th Gen Intel® Raptor Lake H-Series (45W), P-Series (28W), U-Series (15W) Processor onboard
Intel® Iris® Xe Graphics on i7/i5 processors
Supports 4 Independent Displays up to 4K (3DDI+eDP)
2 x SODIMM support up to 64GB (2x 32GB) DDR5 4800MT/s max
Supports 4 x USB 3.2 Gen2, 8 x USB 2.0
9V-19V Wide Range DC-In

System
CPU	13th Gen Intel® Raptor Lake BGA Processor: Intel® Raptor Lake H-Series (45W) Intel® Raptor Lake P-Series (28W) Intel® Raptor Lake U-Series (15W)
Platform Controller Hub	Intel® Raptor Lake SoC Integrated
System Memory	2 x SODIMM support up to 64GB (2x 32GB) DDR5 4800MT/s max
BIOS	AMI uEFI BIOS, 128 Mbit SPI Flash ROM
I/O Chip	EC ITE IT5782
Watchdog Timer	H/W Reset, 1sec. ~ 65535sec. and 1sec./step
H/W Status Monitor	Monitoring System Temperature, Voltage and FAN Status with Auto Throttling Control
TPM	TPM 2.0
OS Support	Win 10, Win 11, Linux
Display
Chipset	Intel® Iris® Xe Graphics on i7/i5 processors Intel® UHD Graphics on i3/Celeron® processors Intel® Gfx up to 96 EU
Resolution	GPU Feature Support Intel® Iris Xe or UHD Graphics Core Architecture, max. 96EUs, supporting 4 concurrent display combinations of DisplayPort/HDMI/LVDS/eDP/VGA and Display alternative mode through USB4/Thunderbolt4 outputs 1x 8K30 or 4x 4K @60. Digital Display Interface (DDI) 1/2/3 supporting DP 1.4a, HDMI 2.1, DVI VGA: max. resolution 1920x1200 @60Hz LVDS: max. resolution 1920x1200 @60Hz in dual mode eDP: Optional
Multi-Display	Supports 4 Independent Displays up to 4K (3DDI+eDP)
Ethernet
Chipset	Intel® I226-LM/IT Ethernet Controller (2.5GbE)
Interface	10/100/1000/2500 Base-Tx GbE compatible
Audio
Chipset	Intel® HD Audio
I/O
PCI Express	1 x Gen4 PCIe x8 (Select SKU, H series) 2 x Gen4 PCIe x4 7 x Gen3 PCIe x1 (2 Lanes shares with SATA)
USB	Supports 4 x USB 3.2 Gen2 8 x USB 2.0
SATA	Supports 2 x SATA III (6.0Gb/s)
UART	2 x UART
Others	8-bit GPIO, LPC, I2C, SMBus, SPI
Mechanical and Environment
Power Requirement	9V-19V Wide Range DC-In
ACPI	Single power ATX supports S0, S4, S5 ACPI 5.0a Compliant
Power Mode	AT/ATX
Operating Temperature	Operating Standard: 0 ~ 60 °C (32 ~ 140 °F) Operating Industrial (select SKUs): -40°C ~ 85°C (-40°F ~ 185°F)
Storage Temperature	-40°C ~ 85°C (-40°F ~ 185°F)
Operating Humidity	40°C @ 95% Relative Humidity, Non-condensing
Form Factor	PICMG COM R3.0 Type 6 COM Express Module
Certification Information	Compliant to CE, FCC Class B, RoHS Compliant
Dimensions	3.74" x 4.92" (125mm x 95mm)
Weight	0.44lbs (0.2kg)

* All product specifications and product images are subject to change without notice. Last update: 11/07/2023

Please Note - By downloading the files from BCM website, you agree to accept the terms and conditions.

Document
Datasheet

Model Name	Description
ESM-RPL	Please contact BCMSales@bcmcom.com for details.
