MAB-T600-B1 Coming Soon
Medical Grade Full Feature Box PC, 60601-1 Certified, 500W PSU. 4xDDR5 ECC, 4xDP, 6xUSB3.2
- LGA 1700 Socket supports 12th/13th/14th Gen Intel® Core™ i 9/7/5/3 Processor
- Intel® R680E Chipset
- 4 x DIMM slots support Dual Channel DDR5 memory speed up to 4400MHz with UDIMM, up to 128GB, with ECC support
- 4 x DP++ (1.4a 4k) onboard support 4 Independent Displays
- 2 x Intel® Ethernet Controller I225 (2.5 GbE)
- 1 x Gen5 PCIe x16, 2 x Gen4 PCIe x4, 1 x Gen3 PCIe x4
- External USB (Rear IO): 6 x USB 3.2 Gen 2x1, 1 x USB 3.2 Gen 2x2 Type C
- External USB (Front IO): 2 x USB 2.0
- 4 x SATA III RAID 0, 1, 5, 10
- Storage option: 2 x 2.5” SATAIII HDD/SSD Drive or 2 x 3.5” SATAIII HDD/SSD Drive
- TPM 2.0
- IPX1 Grade Protection. IPX1 on the top and front sides, providing resistance against dripping water to prevent liquid damage
- Designed with 4 Reserved Expansion Slots for PCIe Add-on Cards, Perfect for Diverse Applications
- 500W Medical Grade PSU Outlet
- Smart Fan Control
- 0~40°C (32˚F ~ 104˚F) Operating Temp
