NUC-ADLN Alder Lake N 3.5in SBC NUC-ADLN Alder Lake N 3.5in SBC NUC-ADLN Alder Lake N 3.5in SBC Rich External IO ports

NUC-ADLN Sampling Now

Compact, Slim Fanless Embedded Computer with Intel® Processor N97 quad-core, and 64GB eMMC onboard

  • Motherboard Inside: ECM-ADLN-N97 3.5" SBC
  • Intel® Processor N97 onboard
  • 1 x SODIMM socket supports DDR5 4800 MT/s up to 16GB
  • 64GB eMMC Onboard
  • 2 x DisplayPort 1.4b 4K@60Hz
  • 2 x LAN, Intel® Ethernet Controllers I226-V
  • 3 x USB 3.2 Gen 2, 2 x USB 2.0
  • 1 x USB Type C OTG
  • 1 x COM Port
  • 1 x Combo Audio Jack
  • 1 x M.2 2242/3042 B-Key, 1 x M.2 2230 E-Key
  • 12V to 24V DC Input, Lockable DC Jack
  • TPM 2.0
  • Fanless Operation
  • 8.46" x 5.75" x 1.97"
  • Supports Windows 10/11, Linux Ubuntu
Related Products

Intel® Edge Software-Qualified Hardware for AI and Edge Computing

Experience seamless edge computing solutions with this product, proudly listed on the Intel Edge Software Recommended Hardware. This motherboard has undergone rigorous lab testing, ensuring optimized power and performance when paired with Intel's software packages. Unlock the full potential of your AI and Edge Computing applications with our hardware platforms.

Explore on Intel® Edge Software Recommended Hardware

System
Motherboard ECM-ADLN-N97 3.5" SBC
CPU Intel® Processor N97, quad-core, 6M Cache, up to 3.60 GHz, up to 12W TDP
Intel® Alder Lake N Platform
System Memory 1 x SODIMM socket supports DDR5 4800 MT/s up to 16GB
BIOS AMI 256Mb uEFI BIOS
Display Intel® UHD Graphics
Support Dual Displays
Ethernet 2 x Intel® Ethernet Controller I226-V (2.5GbE)
Audio Realtek HD Audio Codec
Expansion 1 x M.2 E-Key 2230, CNVi Support (PCIe x 1 + USB 2.0)
1 x M.2 B-Key 2242/3042 with Nano SIM Card Socket (PCIe x1, SATAIII, & USB)
64GB eMMC Onboard
Storage 64GB eMMC Onboard
TPM TPM 2.0
OS Support Win 10, Win 11, Linux Ubuntu
I/O - Front
USB 2 x USB 2.0
Power 1 x Power Button
Reset 1 x Reset Button
LED 1 x HDD LED
I/O - Rear
Display 2 x DisplayPort++ 1.4b 4K@60Hz
USB 3 x USB 3.2 (Red)
1 x USB Type C OTG
LAN 2 x RJ45
DC 1 x Lockable DC Jack
Audio 1 x Combo Audio Jack
SMA 2 x Knockout for SMA Connectors
COM 1 x COM Port
Mechanical and Environment
Power Type 12V-24V Wide Range DC-In
Power Adapter 19V 120W Power Adapter
Cooling Fanless through Aluminum Fin
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20° C ~ 75° C (-14°F ~ 167°F)
Operating Humidity 5% to 85% non-condensing
Dimensions 8.46" x 5.75" x 1.97" (215x146x50mm)
Weight approx 4 lbs (1.8 kgs)
Certification Information CE, FCC Class B, RoHS

* All product specifications and product images are subject to change without notice. Last update: 08/23/2024

Document
Datasheet
BIOS Description
Note This product is equipped with the ECM-ADLN-N97 3.5" SBC motherboard inside. Please check ECM-ADLN-N97 product page for BIOS.
Driver Description
Note This product is equipped with the ECM-ADLN-N97 3.5" SBC motherboard inside. Please check ECM-ADLN-N97 product page for drivers and manual.
Date Description Download
Note This product is equipped with the ECM-ADLN-N97 3.5" SBC motherboard inside. Please check ECM-ADLN-N97 product page for Product Change Notice.
Model Name Description
NUC-ADLN-N97 ECM-ADLN-N97 3.5" SBC inside, Intel® Processor N97 Onboard, up to 12W TDP
Included 19V 120W Power Adapter
US Power Cord
