MX150N Coming Soon

Intel® Processor N150 (6W TDP) Quad-core Soc, Intel® Twin Lake platform
Low-profile design, Value-Packed Thin Mini ITX Motherboard
Integrated Intel® UHD Graphic, supports 3 Independent Displays: 2 x DP 1.4a 4K, 1 x HDMI 1.4b, LVDS/eDP
Dual 2.5GbE LAN: 2 x Intel® Ethernet Controller I226-V
1 x USB Type C
3 x USB 3.2 Gen2 Type A, 4 x USB 2.0
6 x COM/Serial Ports
Expansion Slots: M.2 E-Key, M-Key, B-Key, PCIe x1
12V-24V Wide Range DC-In
TPM 2.0
Passive Cooling with Optional Cooling Fan

System
CPU	Intel® Processor N150 (6W TDP), Quad-core SoC processor, formerly Twin Lake Platform
System Memory	1 x SO-DIMM socket supports DDR5 4800MHz up to 16GB, non-ECC Support
BIOS	256Mb SPI BIOS
Expansion	1 x PCIe x1 Open Ended 1 x M.2 E-Key 2230 (PCIe x1 & USB 2.0) 1 x M.2 M-Key 2280/2242 supports NVMe (PCIe x2) 1 x M.2 B-Key 3042 with Nano SIM Socket (SATA III & USB 3.2)
TPM	TPM 2.0
Supported OS	Win 11 Linux
Display
Chipset	Intel® 12th Gen UHD Integrated Graphic
Display Output	2 x DisplayPort 1.4a 4K@60Hz 1 x HDMI 1.4b 1 x eDP (Optional)
Multi-Display	Supports 3 Independent Displays
Ethernet
Controller	2 x Intel® Ethernet Controller I226-V (2.5GbE)
Interface	2 x RJ45 LAN
Audio
Audio Codec	Realtek HD Audio Codec
External I/O
Display	2 x DisplayPorts (DP++) 1 x HDMI
USB	3 x USB 3.2 Gen2 Type A 1 x USB 3.2 Gen2 Type C
LAN	2 x RJ45
Audio	Line-out, Mic-in
DC Power	1 x DC-in
Internal I/O
Display	1 x LVDS Header 1 x eDP Header (Optional)
USB	2 x USB 2.0 Header (4 Ports)
COM Port	2 x RS-232/422/485 Headers 4 x RS-232 Headers
Other	1 x 8-bits GPIO Header I²C, SMBUS, 4-pin DC-in Connector
Mechanical and Environment
Power Requirement	12V-24V Wide Range DC-In
Operating Temperature	0°C to 60°C (32°F ~ 140°F)
Storage Temperature	-20°C ~ 80°C (-4°F ~ 176°F)
Operating Humidity	5% ~ 90% Relative Humidity, Non-condensing
Cooling Design	Passive Cooling with Optional Cooling Fan
Form Factor	Mini ITX
Dimensions (L) x (W)	6.7" x 6.7" (170mm x 170mm)
Regulatory Compliance	FCC Class B/CE UL/CB, RoHS and REACH Compliant
Weight	0.88 lbs (0.4 KG)

* All product specifications and product images are subject to change without notice. Last update: 05/05/2025

Please Note - By downloading the files from BCM website, you agree to accept the terms and conditions.

Document
Datasheet

BIOS Version	Revision Note	Download

Drivers	Download

Product Change Notice (PCN) Click Here to receive future PCN notifications automatically.

Date	Description	Download

Model Name	Description
MX150N	Mini ITX with Intel® Processor N150 onboard
Accessory Included	1 x Full Height I/O Shield 1 x Low-profile I/O Shield
